Reef Tank Lighting: Seven Metal Halides Over Five Reef Zones

Reef Tank Lighting — Seven Metal Halides Over Five Zones

My Multizone Reef
November 7, 2026
12 min read
The lighting plan at a glance
Previous tank
40-gallon reef under six 110 W VHO tubes
Reef crest
Two 175 W metal halides, 6,500 K
Upper slope
One 175 W metal halide, 14,000 K
Lower slope
One 175 W metal halide, 20,000 K
Back reef
One 175 W metal halide, 10,000 K
Lagoon
Two 175 W metal halides, 5,500 K
Total
Seven 175 W lamps, about 1.2 kW

Lighting my multi-tier reef system was perhaps the most time-consuming part of the whole project, but it was also the most fun and the most rewarding in terms of what I learned. Aquarium lighting has always been a controversial subject, and with a multitude of products on the market, anyone shopping for reef lighting can find themselves confused. I had some experience with lighting, but nothing on the scale of this new system. This post describes how I lit each of the five reef zones, what I would change, and what the experience taught me about light and corals.

How was my earlier reef lit?

My 40-gallon reef system was lit by six 110-watt very high output fluorescent tubes. Before the multi-zone project I had not had the chance to experiment with different lighting combinations. In fact, the hood I designed and built for the 40-gallon tank was my first attempt at building aquarium lighting. VHO tubes were one of the main ways to light reef tanks at the time, alongside metal halides and standard fluorescent tubes. They gave good, even light over a shallow tank, but they lost output as they aged and needed frequent replacement.

reef tank lighting: Reef Tank Lighting: Seven Metal Halides Over Five Reef Zones
reef tank lighting

What was reef lighting like in the early 1990s?

When I built the system, reef lighting was going through a rapid change. A few years earlier, many hobbyists had believed that stony corals simply could not be kept alive in aquariums, partly because the lighting of the time was far too weak. Standard fluorescent tubes over a deep tank delivered only a fraction of the light a shallow reef receives. Very high output fluorescent tubes and metal halide lamps changed that. Reef keepers in Germany and elsewhere showed that with intense light, strong skimming and live rock, small-polyp stony corals could not only survive but grow, and the hobby moved quickly to adopt halides.

The lamps themselves were still crude by later standards. Colour temperatures were limited, many bulbs were designed for warehouses rather than aquariums, and the bluer lamps that later became standard were only beginning to appear. Ballasts were heavy, inefficient and hot. Choosing a different kelvin rating for each of five zones meant hunting for bulbs from several sources. That made the project slower, but it also made it an education.

Did I use actinic supplements?

Many reef keepers of the period added blue actinic fluorescent tubes alongside daylight halides to bring out coral fluorescence and shift the overall colour towards blue. My approach was different: I chose the halide colour temperature itself to set the character of each zone, using bluer lamps over the deeper tanks rather than adding separate actinic tubes. The result was a system in which each tank had a visibly different light, which is exactly what I wanted, though a blue supplement over the shallower tanks would probably have made their corals look more vivid to the eye.

What was the goal for the new system?

I saw the new system as my chance to try anything I wanted, and I welcomed the opportunity. The goal was to match the colour temperature and intensity of light over each zone of the reef to the conditions in that zone in the wild. On a real reef, light changes with depth: the shallow crest and back reef receive intense, full-spectrum sunlight, while the slopes receive progressively dimmer, bluer light as water absorbs the red and yellow wavelengths. So I set out to light each tank differently, using different wattages and different colour temperatures.

How was each zone lit?

Starting with the lagoon, I used two 175-watt metal halides at 5,500 K. Ideally they would have been much brighter, such as 400-watt metal halides. But the lagoon tank was shallow, and very bright lamps over shallow water would have caused a lot of trouble with nuisance algae. That limited me to 175-watt lamps.

The back reef was lit by a single 175-watt 10,000 K metal halide. I would have liked something a little more intense there. I chose 10,000 K, but in hindsight I probably should have used a 6,500 K lamp. The back reef is a shallow, usually flat area that in the wild receives intense, relatively warm light.

The lower slope tank had a 20,000 K 175-watt metal halide. I felt that was a fairly accurate choice and a good one for that tank. The upper slope had a 14,000 K 175-watt halide. The reef crest used two 175-watt 6,500 K metal halides, the warmest and most intense combination over any of the display tanks except the lagoon.

Why did colour temperature vary so much?

Colour temperature, measured in kelvin, describes how warm or cool white light looks. Lower values, such as 5,500 or 6,500 K, are yellow-white, close to midday sunlight near the surface. Higher values look progressively bluer: 10,000 K is crisp white, 14,000 K noticeably blue-white, and 20,000 K distinctly blue. By running warm lamps over the shallow zones and blue lamps over the deeper ones, I was imitating, in a rough way, the shift in light with depth on a reef.

Kelvin ratings are only a crude guide to the spectrum a lamp produces, and lamps from different makers with the same rating could look quite different. They also shift as the bulb ages. But as a way of giving each zone its own character, the approach worked. Corals in each tank grew and coloured in ways that reflected their light.

How did light spill between tanks affect things?

Because the five tanks were staggered close together, light from one lamp spilled onto neighbouring tanks. The lower slope tank, for example, received some light from the crest lamps above and beside it, and the back reef received light from the crest. The clean plan of one colour temperature per zone was therefore never entirely consistent in practice. That turned out to be useful as well as frustrating. On a few occasions I found that a coral coloured better at the edge of one tank, under a mix of two lamps, than anywhere in the tank I had planned for it, and I moved it accordingly.

What happened when I increased intensity?

As time went on, I modified the lighting to increase intensity over the system. More light meant faster coral growth and better colour in the light-hungry corals, but it also meant a higher risk of nuisance algae, particularly over the shallow tanks where intense light reached the bottom. I countered this by dropping the temperature with the chiller and, to a lesser extent, increasing pH and salinity. Those changes, together with good source water and nutrient control, warded off much of the nuisance algae that would usually come with increased intensity over such shallow tanks.

Why are metal halides hot?

A 175-watt metal halide draws 175 watts of power continuously while it is on, and most of that ends up as heat in the room or the water. Seven of them over my system drew about 1,225 watts, plus their ballasts, for many hours a day. That heat, together with the pumps, is why my chiller sometimes ran even in winter. Metal halides are normally hung some distance above the water and cooled with fans, and anyone using them must plan for the heat they add to both the tank and the room.

What did I learn about light and coral colour?

The biggest lesson was how strongly light shapes coral colour. The same coral could be brown under one lamp, pale under another and vividly coloured under a third, depending on intensity and spectrum. Many coral colours come from proteins that the coral produces partly in response to light, including fluorescent proteins that glow under blue light and pigments that may help protect the coral’s symbiotic algae from too much light. Change the light and the coral changes its pigments, often over weeks.

I also learned that corals need time to adjust to new light. A coral moved suddenly from dim to bright light could bleach, and one moved from bright to dim could brown. Every move or lamp change had to be gradual.

What is the right light for each reef zone?

In general terms, the crest and back reef call for the most intense light, with a relatively full, warm spectrum. The upper slope calls for strong light that is slightly bluer. The lower slope calls for moderate, blue-dominated light. A lagoon with seagrasses and mangroves needs bright, warm, plant-friendly light, which is why I used 5,500 K lamps there, though as noted the shallow water limited how much I could use. Corals from each zone can then be placed under light similar to what they evolved under.

How would I light the system today?

Today I would use programmable LED fixtures, one or more over each zone. LEDs let you set intensity and spectrum separately for each tank, run cooler at the water, use far less power and can imitate sunrise, sunset and even cloud cover. I would set the crest and back reef to high intensity with a broad, relatively white spectrum; the upper slope to strong light with more blue; and the lower slope to moderate, mainly blue light. The lagoon would get a bright, warm-white spectrum suited to seagrass and mangroves, with careful attention to algae. A PAR meter would let me measure, rather than guess, the light at each level.

How long were the lights on?

Long photoperiods add little for corals and encourage algae. A typical reef photoperiod is about 8 to 10 hours of main light, with shorter periods of actinic or blue light before and after to imitate dawn and dusk. With several halides it is also possible to stagger lamps so that intensity rises and falls through the day. Whatever the schedule, consistency matters most; a timer or controller should keep it identical every day.

What would I change about my lighting plan?

I would light the back reef with a warmer, more intense lamp, probably a 6,500 K halide, as described above. I would like to have used brighter lamps over the lagoon, if I could have found a way to control algae in shallow water under that intensity. I would design the hood and the spacing of tanks to reduce light spill between zones, or else use it deliberately. And I would budget more carefully for heat, since the lamps were one of the main reasons the chiller had to run as much as it did.

What did VHO and metal halide teach me together?

Moving from six VHO tubes over one tank to seven halides over five tanks showed me the strengths of each. Fluorescent tubes give even light with little shadow and little shimmer; halides give intense, shimmering point-source light that penetrates deeply and makes the reef look like sunlight on a shallow sea. Modern reef lighting tries to combine the two, with LED point sources for intensity and shimmer and T5 tubes or wide-spread optics for evenness. The principle I followed in the 1990s, matching light to zone, still guides how I think about reef lighting.

How do you acclimate corals to new lighting?

Whenever a lamp was replaced or a coral moved, I had to give the corals time to adjust. New metal halide bulbs are noticeably brighter than ones that have run for a year, so a fresh lamp could shock corals that had grown used to the dimmer output of the old one. The usual approaches are to raise the fixture higher for the first few weeks, to replace lamps one at a time rather than all at once, or to shade the tank with a layer of fine mesh that is removed gradually. With modern LEDs the same result is achieved by starting a new fixture at reduced intensity and raising it a few percent each week. In every case, watch the corals: paling or bleaching on upper surfaces means too much too soon, while browning and stretching towards the light mean too little.

How should reef lighting be maintained?

Metal halide bulbs and fluorescent tubes lose output and shift in colour as they age, so they need replacing on a schedule, typically about once a year for halides and more often for some fluorescent tubes, even if they still light up. Salt spray and dust on lamps, reflectors and glass shields cut light significantly, and should be cleaned off regularly with fresh water. Ballasts and fans should be checked, because a failed fan can let a fixture overheat. With seven lamps over five tanks, as in my system, that cleaning becomes a regular part of the maintenance routine rather than an occasional job.

From My Reef Tank: My Original Notes

Aquarium lighting this multi-tier reef system was perhaps the most time consuming, but also the most fun and rewarding from the standpoint of knowledge. Overall, aquarium lighting is a very controversial issue, with a multitude of products the consumer seeking aquarium lighting often finds himself or herself confused. I had some experience with aquarium lighting, but nothing to the scale of this new reef aquarium system.

I figured this was my chance to try anything I wanted and I welcomed this opportunity. I wanted to try to match the Kelvin temperature over each section of the coral reef in my reef aquarium, so I set out to illuminate them all differently. I wanted different wattage and different Kelvin temperature of the bulbs.

Starting with the lagoon, I ran two 5500k 175w Metal Halide bulbs; ideally they would have been much brighter like 400 watt Metal halides aquarium bulbs. At the shallow depth bright bulbs in the color spectrum would have caused allot of complications with nuisance algae. This forced me to use the 175w metal halides.

The back aquarium reef was one 10k 175w Metal halide; I would have liked to use something a bit bluer and a bit more intense. I went with the 10k, but I most likely should have gone with a 6500k metal halide. The back reef is a shallow area usually pretty flat.

The lower aquarium reef was a 20k 175w Metal halide. I did feel that was fairly accurate and a good choice for the aquarium setup. The upper reef a 14k 175w Metal halide and the aquarium reef crest used 2 175w 6500k Metal Halide bulbs. As time progressed I modified the lighting setup to increase intensity over than aquarium. By dropping the temperature with the chiller and increasing the PH and salinity to a lesser extent, I was able to ward off a large bit of the nuisance algae that would typically be associated with increased intensity over such a shallow reef aquarium system.

Frequently asked questions

How was my multi-zone reef lit?

With seven 175-watt metal halides, from 5,500 K over the lagoon to 20,000 K over the lower slope.

Why not use 400 W lamps over the lagoon?

The shallow lagoon tank would have suffered nuisance algae under that intensity.

Which lamp would I change?

The back reef’s 10,000 K lamp; a 6,500 K halide would have suited it better.

How did I control algae as lighting increased?

By lowering temperature with the chiller and slightly raising pH and salinity, with good source water.

What lit my earlier 40-gallon reef?

Six 110-watt VHO fluorescent tubes in a hood I built.

What would I use today?

Programmable LED fixtures, set separately for each zone and checked with a PAR meter.

Sources & further reading
  1. Delbeek, J. C. and Sprung, J. (1994), The Reef Aquarium, Vol. 1, Ricordea Publishing
  2. Riddle, D., Advanced Aquarist, articles on reef lighting and coral colour
  3. Blane Perun, lighting notes for the 40-gallon and multi-zone reef systems
